Leak-Proof Reliability – Precision D-profile design ensures a tight, uniform compression seal, preventing leaks and protecting product integrity
Quick Installation & Maintenance – Simple drop-in placement enables rapid assembly and disassembly, reducing downtime during maintenance and cleaning
CIP/SIP Compatibility – All materials are suitable for Clean-In-Place (CIP) and Sterilize-In-Place (SIP) procedures, maintaining hygiene without disassembly
Versatile Industry Applications – Ideal for dairy processing, beverage production, food manufacturing, pharmaceutical production, biotechnology, and cosmetics industries
Full Regulatory Compliance – Certified to 3-A Sanitary Standards, FDA food contact regulations
Material Traceability – Full material traceability and optional certification available for quality assurance
The DIN11851 Seal operates through a simple yet highly effective compression-sealing principle within a DIN 11851 union assembly
Placement – The D-seal gasket is placed into the dedicated groove on the male part (Gewindestutzen) of the DIN 11851 union
Alignment – The liner (Einlegestutzen) is brought into position, aligning its sealing face with the gasket
Compression – The slotted nut (Nutmutter) is tightened using a hook spanner (C-spanner), compressing the gasket between the male part and liner
Sealing – The D-shaped cross-section deforms under compression to fill the sealing gap completely, creating a crevice-free, leak-tight seal
Disassembly – Loosening the slotted nut allows for instant disassembly for inspection, cleaning, or gasket replacement
