Flow Termination – Effectively seals off the end of a piping system, preventing fluid flow and maintaining system integrity
DIN 11851 Standard Compliance – Manufactured to DIN 11851 sanitary union standards, ensuring compatibility with DIN-13 nuts, DIN-15 males, and other DIN series components
Hygienic Crevice-Free Design – Smooth interior and exterior surfaces minimize bacterial growth and ensure sanitary integrity
High Corrosion Resistance – Constructed from premium 304 and 316L stainless steel for long-lasting durability in demanding environments
CIP/SIP Compatible – Designed to support Clean-In-Place and Sterilize-In-Place procedures with no dead zones
Wide Size Range – Available from DN10 to DN150 to suit diverse system requirements
Precision Engineered – Uniform wall thickness and strict dimensional control ensure reliable performance
Effective System Isolation – Provides a reliable seal to isolate sections of piping for maintenance, cleaning, or system modifications
Hygienic Operation – Crevice-free design and smooth surface finish meet GMP/HACCP standards, making it suitable for sterile piping systems
Easy Integration – Standard DIN 11851 design ensures seamless compatibility with existing DIN sanitary union systems
Long Service Life – Stainless steel construction with 3A certification ensures superior durability under repeated sanitization cycles
Versatile Applications – Suitable for food processing, beverage production, pharmaceutical manufacturing, biotech, dairy, cosmetics, and semiconductor industries
Maintenance-Friendly – Supports CIP and SIP cleaning without requiring removal from the system
The DIN Blank Liner DIN-14B operates as a sealing component within a DIN 11851 sanitary union system:
Union System Integration – The DIN system consists of four key components: DIN-13 (Nut), DIN-14 (Liner/Welding Liner), DIN-15 (Male), and DIN-16 (Blank)
Connection – The blank liner (DIN-14B) is installed at the end of a piping run, serving as a termination point
Sealing – A DIN-style gasket (D-shaped profile) is placed between the blank liner and the mating fitting, creating a hygienic, leak-proof seal
Securing – The DIN-13 nut is threaded over the connection, compressing the gasket to form a pressure-tight seal
Flow Blocking – The blank liner effectively blocks fluid flow, isolating the piping section for cleaning, maintenance, or system modification
This design provides a permanent yet serviceable seal, combining the reliability of a welded connection with the flexibility of a removable fitting.
