Concentric Flow Reduction – Reduces pipe diameter from a larger size to a smaller size while maintaining a common centerline, ensuring smooth fluid transition without offset
DIN 11852 Standard Compliance – Manufactured to DIN 11852 / EN 10374 standards, ensuring dimensional accuracy and interchangeability
Weld-On End Connections – Designed for permanent butt-weld installation, suitable for CIP (Clean-In-Place) and SIP (Sterilize-In-Place) systems
Hygienic Crevice-Free Design – Smooth internal and external surfaces minimize bacterial growth and ensure sanitary integrity
High Corrosion Resistance – Constructed from premium 304 (1.4301) and 316L (1.4404) stainless steel
Polished Surface Finish – Ra < 0.8 μm (240 grit) internal and external polish for easy cleaning and superior hygiene
Smooth Flow Transition – Concentric design ensures favorable flow characteristics with minimal turbulence, pressure drop, or air entrapment
Hygienic Operation – Crevice-free design and polished surface finish meet 3A Sanitary Standards, eliminating pooling and cross-contamination risks
Permanent, Reliable Connection – Butt-weld installation provides a secure, leak-proof joint that does not require disassembly
CIP/SIP Compatible – Designed to support Clean-In-Place and Sterilize-In-Place procedures with no dead legs or harborage sites
Versatile Applications – Suitable for food processing, beverage production, dairy, pharmaceutical, biotech, and fine chemical industries
Long Service Life – Stainless steel construction with 3A certification ensures superior durability under repeated sanitization cycles
The DIN 11852 Concentric Reducer operates as a permanent transition component within a sanitary piping system:
Positioning – The reducer is installed at the point where a larger diameter pipe transitions to a smaller diameter pipe
Welding – The weld-on ends are butt-welded to the adjacent tubing sections, creating a permanent, hygienic joint
Flow Redirection – The concentric design smoothly guides fluid from the larger diameter to the smaller diameter while maintaining a common centerline, ensuring efficient flow without offset
Hygienic Operation – The smooth, crevice-free internal surface prevents product residue buildup and supports effective CIP cleaning
System Integration – Once welded in place, the reducer becomes a permanent part of the piping system, providing reliable, long-term service
