S2WCL 90Degree Bend SMS Short

Key Features

• 90° Flow Direction Change – Efficiently redirects fluid flow at a right angle with a short radius, enabling compact system layouts

• SMS 1145 Standard Compliance – Manufactured to exacting SMS 1145 dimensional and tolerance specifications, ensuring full compatibility with other SMS sanitary components

• Short Pattern Design – Compact short radius reduces overall system footprint, material usage, and installation space requirements

• Welding Ends – Beveled ends designed for automatic orbital or manual TIG welding, creating a permanent, leak-proof, and crevice-free joint

• Hygienic Crevice-Free Interior – Smooth internal surface with no dead zones, minimizing bacterial growth and ensuring sanitary integrity

• High Corrosion Resistance – Available in 304 and 316L stainless steel, offering exceptional durability in demanding process environments

• Wide Size Range – Available from DN 25 to DN 100 (and larger upon request) to suit diverse system requirements

• Precision Surface Finish – Standard Ra ≤ 0.8 μm (electropolished) meeting 3A and dairy industry standards

Key Advantages

• Space-Saving Design – Short pattern significantly reduces the bend radius and overall system footprint, making it ideal for compact equipment and tight installations

• Permanent, Hygienic Joint – Welded connection provides a leak-proof, crevice-free seal that meets 3A sanitary standards for food and dairy equipment

• Superior Cleanability – Crevice-free design supports CIP (Clean-In-Place) and SIP (Sterilize-In-Place) procedures without disassembly

• Cost-Effective System Layout – Short radius allows for tighter piping configurations, reducing pipe length, material costs, and installation time

• Long Service Life – Premium stainless steel construction and smooth finish ensure exceptional durability under repeated high-temperature sterilization and chemical cleaning

• Versatile Applications – Suitable for dairy processing, food and beverage production, pharmaceutical manufacturing, biotech, cosmetics, and chemical industries

• Interchangeable Standard – SMS 1145 compliance ensures seamless integration with all standard SMS components in existing systems

How It Works

The S2WCL 90 Degree Bend SMS Short functions as a directional change component within an SMS sanitary piping system:

1. Welding Connection – The weld ends of the bend are welded to stainless steel pipes or tubing using orbital or manual TIG welding, creating a permanent, homogenous, crevice-free joint

2. Flow Redirection – The 90° bend body smoothly redirects fluid flow at a short radius, efficiently navigating around obstacles and optimizing space utilization

3. System Integration – Once welded in place, the bend becomes an integral part of the SMS piping system, connecting seamlessly with SMS union fittings, valves, and equipment

4. Hygienic Operation – The smooth, crevice-free interior prevents bacterial accumulation, ensuring product purity and meeting strict sanitary standards

5. CIP/SIP Compatibility – The short bend design allows cleaning and sterilization fluids to flow through effectively, maintaining system cleanliness without disassembly

This design provides a permanent, reliable, and hygienic solution for 90° directional changes in space-constrained sanitary piping systems.

Why Choose Us

• Certified Quality – All our S2WCL SMS Short Bends are 3A Sanitary Standards certified, meeting the highest industry requirements for dairy and food processing equipment. We also hold CE certification and ISO 9001 quality management system certification, ensuring consistent product excellence

• Premium Materials – We use only high-grade 304 and 316L stainless steel sourced from certified mills, offering exceptional corrosion resistance, weldability, and longevity

• Precision Manufacturing – Every bend is machined to SMS 1145 tight tolerances with a surface finish of Ra ≤ 0.8 μm (electropolished) to meet stringent hygienic standards

• Stringent Quality Control – Each fitting undergoes dimensional inspection, surface finish testing, material verification, and pressure testing to ensure 100% compliance

• Extensive Size Range – From DN 25 to DN 100, we offer a full range of SMS sizes to meet your specific system requirements

• Competitive Pricing – Direct manufacturing capabilities allow us to offer factory-direct pricing without compromising quality

• Full Traceability – Every fitting is supplied with EN 10204 3.1 material test reports and full traceability documentation for audit compliance

• Expert Support – Our team of sanitary fitting specialists provides technical guidance on welding procedures, material selection, and SMS system integration

• Reliable Supply Chain – Consistent inventory and fast shipping ensure your projects and production lines stay on schedule

• Custom Options Available – We can accommodate special sizes, custom dimensions, or specific surface finish requirements upon request
